Code: HAGHND401H
Wesco Electrical LTD stockists of Hager HAGHND401H, MCCB h630 4P 50kA 400A LSI in stock. Available for express delivery, Shop Today.
Product is unavailable at this time
Out of Stock
Hager HAGHND401H | MCCB h630 4P 50kA 400A LSI
MCCBs | Commercial Distribution | Switchgear & Distribution
The Hager HND401H is a 4-pole moulded case circuit breaker (MCCB) from the h630 frame size, rated at 400A with an LSI (Long time, Short time, Instantaneous) adjustable trip unit and a 50kA breaking capacity. It is designed to provide overload and short-circuit protection on higher-current commercial and industrial distribution circuits.
Features:
- 4-pole, 400A rated current
- LSI adjustable protection settings for tailored discrimination
- 50kA short-circuit breaking capacity
- Rated for 220/690V operation
Benefits:
- Adjustable LSI settings allow fine-tuning of protection to suit the installation
- High breaking capacity suited to demanding industrial supplies
- Robust moulded case construction for long service life
A robust protection solution for higher-power distribution circuits.
Product Specification:
| Number of poles: | 4P |
|---|---|
| Number of modules: | 10.5 |
| Rated operational voltage Ue: | 220 / 690 V |
| Frequency: | 50/60 Hz |
| Trip unit: | LSI |
| Rated current: | 400 A |
| Breaking capacity: | 50 kA |
| Standard: | IEC 60947-2 |
